Battery Testers, EBC-A10H Multifunction Electronic Load Tester 0-30V12V Battery Capacity Power Bank and DC Power Supply Test 10A 150W

SpecificationsVoltage Setting Range: 0-30.00V, stepper 0.01V (During charging, the maximum voltage is limited to power voltage -2V)CHG-CV: Current and voltage can be set at a constant voltage (only for batteries)during dischargingDischarging mode:DSC-CC: Discharging batteries at a constant current, support testing battery capacityor current of power suppliesDSC-CP : Discharging batteries at a constant power, for constant powerequipment-like use or testing powerAutomatic Charging/Discharging: The tester supports "charging-discharging-charging"circles for capacity tests.Voltage accuracy: between 0-4.5V, 0.003V, ±0.5%, between 4.5-30V, 0.01V, ±0.5%.Current accuracy: 0.05-10.00A, 0.005A, ±0.5%.Capacity detection: <; 10Ah,0.001AH; 10-100Ah,0.01Ah; > 100Ah,0.1AhFour lines: voltage and current channels separated for high test accuracyLCD display: voltage, current, time, capacity, and etc.PC connection: the tester can connect to a computer through a designated USB-TTL cable for more functions, like graphs, calibration, firmware upgrade, and test circulation.Precautions1)Positive and negative connections should not be reversed. Improper connection could damage the tester.2)Always use the tester within the allowed range.Package List:1 xEBC-A10H Battery Pack Capacity Tester4 x Tester Cables1 x USB to TTL cable1 x Power supply cable

• Battery capacity test:The tester is designed for charging and discharging a wide range of batteries/battery banks, like NiMH, NiCd, LiPo, LiFe and Pb and it supports capacity tests.
• Portable Power Bank Test:This tester supports charging and discharging of portable power banks, as well as testing their capacities.
• Power Performance Test:This tester supports performance and aging tests of various kinds of DC power supplies.
• Charging mode:Standard Charging: Support NiMH, NiCd, LiPo, LiFe and Pb batteries
• Current Setting Range: for charge, 0.05-5.00A, stepper 0.01A (current adjusted automatically when power exceeding limits) for discharge, 0.05-10.00A, stepper 0.01A (maximum current should be power current-0.5A)
